Mini Capacity Fire Pit Electronic Ignition System TOP-500EIS-100-30DC

Mini Capacity Fire Pit Electronic Ignition System

Designed for outdoor fire features with a maximum gas output of 190,000 BTU/hr. These robust, CSA-certified Systems represent the pinnacle of sophistication in fire pit ignition technology.

Experience ultimate peace of mind and effortless control with 30V DC Fire Pit Electronic Ignition. These systems provide the highest level of safety available for gas fire features, as the system continuously monitors the flame, attempting multiple relights if it extinguishes before safely shutting off the gas supply. For seamless convenience, you can light and manage your fire pit using an On/Off switch, Electric Timer, Emergency Stop Button, remote control, wireless light switch, or integration with your swimming pool system or existing home automation system.

Options

Low Voltage – DC – (TOP-500EIS-100-30DC)

• To be used for installations within five feet or less of water features, such as swimming pools, fountains, etc.
• Includes Electronic Valve, Pilot Igniter, and a separate Transformer which can power 2 fire features.

Plug and Play – DC – (TOP-500EIS-100-30DC-110V)

• Included are the Pilot Igniter and an Electronic Valve, which features a 3-prong plug for simplified setup. To operate the fire feature, an external ON/OFF switch is wired into the electrical supply line.

Features

Electronics

• Enhanced protection against moisture and damage
• Reliable Ignition with the Hot Surface Ignition (HSI)
• Fast-responding Thermocouple Flame Sense system
• Integrated LED diagnostics facilitate field service and troubleshooting tasks.

Gas Valve and Pilot Components

• Moisture-resistant features for added protection.
• Stainless steel construction.
• Thermocouple coated with nickel plating for increased durability.
• Waterproof connection for Hot Surface Igniter (HSI), which has a protective cage.
• Waterproof Power Wire connector for added protection.

Mini Capacity Fire Pit Electronic Ignition System Specs:

• Maximum Gas Output: 190,000 BTU/hr
• Inlet / Outlet Size: 1/2” FIP
• Electrical Rating: 30V DC
• -20° to 175° Temp Range with safety shutoff at 175°F
• LED diagnostics for field service and troubleshooting

These units are also available for standard-capacity burners with a maximum BTU rating of 290,000. See our Standard-Capacity Listing for details.

Also available are units for High-Capacity burners with a BTU rating of up to 510,000.

Further Information

• Compatible with both Natural Gas and Liquid Propane (Portable LP Tank or Hard Line LP)
• Mini Capacity Fire Pit Electronic Ignition Systems is perfect for tight spaces such as fire bowls.
• Proper Venting –  All gas fire pit enclosures require a minimum of 18 square inches on two opposing sides.  Fire pits with higher BTUs or extended operating hours may require additional ventilation.
• For LP applications, fire media smaller than 1/2″ is not recommended.
• An Air Mixer for Propane Is Recommended for Propane Burners.
• Installation of a listed manual gas shutoff device is mandatory before the location of the appliance.
• A heat shield/plate or burner pan MUST be installed between the unit and the burner ring to avoid overheating.
• Installation and servicing of this product must be performed exclusively by a qualified installer, service agent, or local gas supplier.

Warranty

Electronics, Gas Valves, Pilot Assembly: Commercial – 6 Months; Residential – 12 Months

Certification

Components are CSA Certified ANSI Z21.97-(2017) / CSA 2.41-(2017) certified
