HPC Rectangular Match Lit Fire Pit Kit with Torpedo Burner

HPC Rectangular Match Lit Fire Pit Kit with Torpedo Burner

The HPC MLFPK Match Lit Series offers this CSA-certified fire pit kit in a rectangular configuration featuring the Torpedo H-Burner. It delivers an impressive flame, and installation and operation are simple and straightforward.

Features:

• CSA Certified.
• Manufactured from #304 stainless steel.
• Lifetime Warranty on the Torpedo HBurner
• Commercial-Grade and Fully Assembled.
• Flex Line and Valve mounting bracket allow for simple installation.
• The flame height is adjustable using the key valve.
• Available for either Natural Gas, Whole-House Propane, or Small-Tank Propane.

Operating Instructions

• To Light: Hold a lit long-stem taper over the burner and open the gas key valve.
• To Adjust the Flame: Use the key to adjust the flame height.
• To Shut Down: Turn the key to the off position. Remove the key for safety.

HPC Rectangular Match Lit Fire Pit Kit with Torpedo Burner Specifications

The Kit comprises a Stainless Steel Round Flat Insert, a Torpedo Penta Burner, a Key Valve with a mounting bracket and a Chrome Key, and a 36″ Flex Line connection.

All Propane configurations include an Air Mixer. The small tank option has an additional Gas Line, 6′ total length (2′ Stainless Steel, 4′ Rubber Hose), and a regulator.

Dimensions and BTU Ratings

The sizes correspond to the internal diameter of the Inserts and do not include the 1.25″ wide lip. The recessed, bowl area of the Insert is 2.5 ” deep.

• The 24″ x 12″ Pan has an 18″ x 6″ H-Burner rated 65,000 BTUs
• The 30″ x 12″ Pan has a 24″ x 6″ H-Burner rated 65,000 BTUs
• The 36″ x 14″ Pan has a 30″ x 8″ H-Burner rated 65,000 BTUs

Related Products

• Wind Guards
• Fire Pit Lids

HPC Rectangular Match Lit Fire Pit Kit Documents:

• PDF HPC MLFPK Match Lit Fire Pit Kit Instructions
• PDF HPC MLPK Match Lit Fire Pit Kit Drawings & Specs
